5/2-way solenoid valve from Airtec with a G 1/8" port, spring return and 24 V DC control voltage. It controls double-acting pneumatic cylinders in automation. IP 65 protection, NBR seal, supplied with coil and plug.
5/2-Way Solenoid Valve G 1/8", Spring Return, 24 V DC - Airtec KM 09511HN 24V
AIRTEC
Original product
Net price (excl. VAT)
€65.26
Item
FL-KM-09511HN-24V
Manufacturer no.
KM 09511HN 24V=
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KM 09511HN 24V=
EAN4050571440428
Customs tariff number84812090
ConditionNew
Artikel
FL-KM-09511HN-24V
The Airtec KM 09511HN 24V is a ready-to-use 5/2-way solenoid valve with a G 1/8" port and mechanical spring return. The control voltage is 24 V DC with a voltage tolerance of ± 10 %.
Benefits
- IP 65 protection class for use in dusty and humid environments
- Body of anodised aluminium and plastic, internal parts of stainless steel and brass
- NBR seals for lubricated and non-lubricated, filtered compressed air
- Temperature range from -10 °C to +70 °C for a wide operating window
- Mechanical spring return provides a defined default position
- Supplied complete with solenoid coil and plug
Technical data
| Function | 5/2-way solenoid valve |
| Actuation | electric, spring return |
| Port | G 1/8" |
| Control voltage | 24 V DC |
| Voltage tolerance | ± 10 % |
| Protection class | IP 65 |
| Solenoid coil form | N (connector size 1) |
| Pressure inlet | port 1 |
| Body material | anodised aluminium and plastic |
| Internal parts | stainless steel and brass |
| Seal | NBR |
| Media | lubricated and non-lubricated, filtered compressed air |
| Temperature range | -10 °C to +70 °C |
| Weight | 0.23 kg |
Applications
The valve is suited to controlling double-acting pneumatic cylinders and actuators in machine and plant engineering, assembly and handling technology and manufacturing automation.
The valve is always supplied with solenoid coil and plug.
