Reduction, Pipe exterior-Ø taps 18 mm bushing 15 mm - Riegler 112489

Reduction, Pipe exterior-Ø taps 18 mm bushing 15 mm, PN max. 315 bar, Stainless steel 1.4571 Suitable for compressed air, liquids, natural gas and hydraulics. Not suitable for nitrogen, oxygen, helium, hydrogen or welding gases!

Technical data

Standards and origin

• Customs tariff number: 73072910
• Country of origin: DE

About Reducers

Reducers bring two pipes of different outside diameter together inside one cutting ring fitting, without a threaded adapter and without an extra sealing point. The range is rated for nominal pressures from 160 to 630 bar and is therefore aimed at hydraulic lines.

What matters when choosing

• Pipe pairing: the socket diameter on both sides must suit the pipes already installed, typical steps being 8/6, 12/10 or 15/12 mm. Each side carries its own cutting ring.
• PN: pressure ratings run from 160 to 630 bar. Size to the highest load occurring in the system, peaks included.
• Material: galvanised steel to DIN 2353 for standard hydraulic duty, stainless steel 1.4571 for corrosive surroundings and aggressive media.
• Installation dimensions: lengths L1 and L2 together with the across-flats sizes SW 1, SW 2 and SW 3 show whether the reducer can still be fitted and reached with a spanner in the planned position.
• Version: part of the range is listed as light series, which matters when combining it with the other fittings of the same line.

Typical applications

• Stepping between pipe runs of different nominal size on hydraulic power units
• Connecting smaller control lines to a larger main line
• Rebuilding and extending existing systems where a different pipe diameter continues the run
• Lubricating oil lines on presses and machine tools
• Hydraulic test rigs working at high pressure ratings

The galvanised steel versions are made to DIN 2353, with stainless steel 1.4571 available alongside. The 109 items in this group come from production in Germany and Italy.
