3/2-Way Limit Switch with Cam, M 5, NC - Airtec E 25 310

The Airtec E 25 310 is a mechanically actuated 3/2-way valve, normally closed (NC), built as a limit switch with cam actuation via lever, roller plunger and cam. It signals end positions in pneumatic control systems and switches compressed air up to 12 bar at the M 5 port.

Benefits

• Mechanical cam actuation with roller plunger for reliable end-position sensing without electrics.
• Anodized aluminium body for corrosion protection and low weight of 0.034 kg.
• Operating pressure 0 to 12 bar covers common pneumatic control circuits.
• Runs on lubricated and non-lubricated compressed air for flexible use in existing systems.
• Pressure inlet possible at any port in the NC/NO version.

Applications

End-position and position sensing on cylinders, workpiece fixtures and feed units, plus mechanical triggering of control functions in machine and fixture building.
