Aventics Soft-start valve 5832115400 PRESSURISING UNIT 230V50HZ 583
€321.31
Excl. 19% VAT ,
excl. Shipping Cost
Article
AVE-5832115400
Manufacturer Nr.
5832115400
PRESSURISING UNIT 230V50HZ 583
Frequently Bought Together
-
This Item:
€321.31Excl. 19% VAT , excl. Shipping Cost
-
Aventics R480739063 HF04-XF-10-40
€2,752.23Excl. 19% VAT , excl. Shipping Cost
-
Aventics R404070043 SEAL KIT PRA/TRB-080-B002
€94.92Excl. 19% VAT , excl. Shipping Cost
Total price
| Activation | Electrically |
| Nominal flow Qn | 3300 l/min |
| Working pressure min. | 3 bar |
| Working pressure max | 10 bar |
| Operational voltage AC at 50 Hz | 230 V |
| Voltage tolerance AC 50 Hz | -10% / +10% |
| Manual override | with detent |
| Pilot valve width | 22 mm |
| Valve type | Spool valve |
| Holding power AC 50 Hz | 8 VA |
| Switch-on power AC 50 Hz | 10 VA |
| Flow conductance C | 11.3 l/(s*bar) |
| Min. ambient temperature | -15 °C |
| Max. ambient temperature | 50 °C |
| Min. medium temperature | -15 °C |
| Max. medium temperature | 50 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air min. | 0 mg/m³ |
| Oil content of compressed air max. | 1 mg/m³ |
| Protection class with connection | IP65 |
| Duty cycle | 100 % |
| Typ. switch-off time | 60 ms |
| Weight | 0.39 kg |
| Housing material | Aluminum |
| Manufacturer Nr. | 5832115400 |
|---|---|
| Manufacturer | Aventics |
| GPSR manufacturer information | AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com |
| Weight | 0.390000 |
| HS-Code | 84819000 |
| Article authenticity | Original product |
| Condition of article | New |
