ISO 15552 Clevis Swivel Mount 125 mm, Stainless Steel 1.4401 - Airtec TC 125 ES
ISO 15552 clevis swivel mount for cylinders with 125 mm bore. Made from 1.4401 stainless steel for corrosive and hygienic environments. Supplied with 4 mounting screws.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The TC 125 clevis swivel mount connects ISO 15552 pneumatic cylinders with a 125 mm bore to the machine frame with a pivoting bracket. The 1.4401 stainless steel makes it suitable for corrosive environments and washdown processes.
Benefits
- 1.4401 stainless steel resists moisture, cleaning agents and aggressive media.
- Dimensioned to fit 125 mm bore cylinders per ISO 15552.
- Pivoting bearing absorbs the angular travel of the piston rod and relieves the rod guide.
- Supplied with 4 mounting screws, ready to install out of the box.
Applications
For the swivelling mounting of ISO 15552 cylinders in size 125 mm in handling, clamping and conveying systems where the piston rod follows a moving load.
Technical data
| Material | 1.4401 (stainless steel) |
|---|---|
| For bore diameter | 125 mm |
| A | 130 mm |
| B | 70 mm |
| D | 25 mm |
| L | 275 mm |
| F | 50 mm |
| M | 140 mm |
| N | 110.0 mm |
| Weight | 3.6 kg |
| Scope of delivery | 1 pc. swivel mount incl. 4 mounting screws |
| Weight | 3.600000 |
| Manufacturer | Airtec |
| Hersteller-Nr | TC 125 ES |
| EAN | 4050571689544 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552 |
