Double-acting compact cylinder from Airtec with 50 mm piston bore and 100 mm stroke. The short body saves installation space, and the built-in magnetic piston enables contactless end-position sensing at up to 10 bar.
Compact Cylinder Double-Acting Ø 50 mm, Stroke 100 mm, Magnetic Piston - Airtec NXDK 50/100
AIRTEC
Original product
Net price (excl. VAT)
€193.51
Item
FL-NXDK-50/100
Manufacturer no.
NXDK 50/100
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.NXDK 50/100
EAN4050571531850
Customs tariff number84799070
ConditionNew
Artikel
FL-NXDK-50/100
The Airtec NXDK 50/100 is a double-acting compact cylinder with a 50 mm piston bore and 100 mm stroke. The short body saves installation space, and the integrated magnetic piston enables contactless end-position sensing via sensors of types D and A.
Benefits
- Double-acting with 100 mm stroke for defined extend and retract motion at up to 10 bar.
- Built-in magnetic piston for contactless position sensing with no added mounting space.
- Stainless steel 1.4305 piston rod, corrosion-resistant and wear-resistant.
- Anodised aluminium body and barrel, light and permanently surface-protected.
- Compact overall length reduces build volume in confined fixtures.
- Operation from -20 to +80 °C with PUR seal.
Technical data
| Head and foot | Anodised aluminium |
| Cylinder barrel | Anodised aluminium |
| Piston rod | Stainless steel 1.4305 |
| Seal | PUR |
| Temperature range | -20 to +80 °C |
| Operating pressure | max. 10 bar |
| Design | with magnetic piston |
| Sensor type | D, A |
| Piston diameter | 50 mm |
| Stroke | 100 mm |
| Piston rod design | through piston rod |
| G1 (piston rod female thread) | M 8 |
| M (air port) | G 1/8" |
| A | 67 mm |
| B | 16 mm |
| C | 6 mm |
| D | 6,7 mm |
| E | M 8 |
| F | 10,5 mm |
| J | 45,5 mm |
| L | 0 mm |
| N | 8,0 mm |
| O | 14,75 mm |
| P | 50 mm |
| Q | 12 mm |
| T | 13 mm |
| U | 6,5 mm |
| Z | 7,5 mm |
| Weight | 1.2 kg |
| Repair kit | NXD 50 REP |
Applications
Suited to clamping and gripping, handling, assembly automation and fixture construction where short strokes are needed in a small footprint. Matching repair kit NXD 50 REP. A piston rod with male thread (-AG) is available as an option.
| Weight | 1.200000 |
|---|---|
| Manufacturer | Airtec |
| Hersteller-Nr | NXDK 50/100 |
| EAN | 4050571531850 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
