Connects instrument and line without rebuilding the plant. The connection is made via thread NPT 1/4". The operating pressure covers 630 bar.
Gauge adapter, NPT 1/4", 630 bar, zinc plated steel, temperature range -20 to +100 °C, M 16x2 (AG)
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€23.54
Item
FL-273290
Manufacturer no.
ME MAAG 14 NPT
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.ME MAAG 14 NPT
EAN4050571485955
Customs tariff number84812010
ConditionNew
Artikel
FL-273290
Frequently Bought Together
-
This Item:
€23.54
-
Safety valve, TÜV type-tested, factory-set and lead-sealed, G 1/2", DN 8, 23.00 bar, brass
€33.16
-
Overflow valve, G 1/2", 12 - 20 bar, DN 15, gunmetal and brass, height 69 mm
€170.84
Total price
Anyone bringing an instrument to an existing line uses this gauge adapter as the transition. The operating pressure extends over 630 bar. The body is made of zinc plated steel. The device is screwed in with NPT 1/4". The temperature range extends over -20 to +100 °C.
Benefits
- Connection thread NPT 1/4" for direct installation in the line
- Temperature range -20 to +100 °C for use in the workshop and in the plant
- Material zinc plated steel determines strength and resistance of the part
- Operating pressure 630 bar as the leading rating of the device
Technical data
| Property | Value |
|---|---|
| Material | zinc plated steel |
| Version | for screwing into the measuring hose |
| Female thread G1 (gauge) | NPT 1/4" |
| Thread G2 (test point) | M 16x2 (male) |
| Bulkhead thread | M 16 |
| Emax [mm] | 12 |
| Operating pressure [bar] | 630 |
| Temperature range [°C] | -20 to +100 |
Applications
Measuring points on hydraulic and compressed air lines, test and service work, retrofitting of pressure gauges.
| Weight | 0.065000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | ME MAAG 14 NPT |
| EAN | 4050571485955 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | zum Einschrauben in den Messschlauch |
| Material | Galvanised steel |
| Temperaturbereich | -20-100 °C |
