Electrically actuated 5/3-way solenoid valve from Airtec with G 1/8" port and 24 V DC control. In the spring-centered mid position all working ports are blocked, so the cylinder can be stopped and held in any position. Anodized aluminium body, protection class IP 65, supplied complete with solenoid coil and connector.
5/3-way solenoid valve G 1/8", closed center, 24 V DC - Airtec M 05530HN
AIRTEC
Original product
Net price (excl. VAT)
€137.34
Item
FL-M-05530HN-24V
Manufacturer no.
M 05530HN 24V=
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.M 05530HN 24V=
EAN4050571471002
Customs tariff number84812090
ConditionNew
Artikel
FL-M-05530HN-24V
The Airtec M 05530HN is an electrically actuated 5/3-way solenoid valve with a G 1/8" port for controlling pneumatic cylinders and actuators. In the spring-centered mid position all working ports are blocked, so the cylinder can be stopped and held in any position. It is switched with 24 V DC.
Benefits
- Closed mid position allows the cylinder to be stopped and held in any position
- Anodized aluminium body with stainless steel and brass internals for a long service life
- Protection class IP 65 for use in harsh industrial environments
- Runs on lubricated and non-lubricated, filtered compressed air
- Supplied complete with solenoid coil and connector, ready to install
- Wide temperature range from -10°C to +70°C
Technical data
| Type | 5/3-way solenoid valve, electrically actuated |
| Flow function | 5/3-way, closed center |
| Actuation | solenoid with spring centering |
| Port | G 1/8" |
| Pressure inlet | Port 1 |
| Control voltage | 24 V DC |
| Voltage tolerance | ± 10 % |
| Standard control voltages | 24 V DC, 230 V AC, others on request |
| Coil design | N (connector size 1) |
| Protection class | IP 65 |
| Body | anodized aluminium and plastic |
| Internals | stainless steel and brass |
| Seal | plastic / NBR |
| Media | lubricated and non-lubricated, filtered compressed air |
| Temperature range | -10°C to +70°C |
| Scope of delivery | valve with solenoid coil and connector |
| Weight | 0.37 kg |
Applications
For controlling double-acting pneumatic cylinders, rotary actuators and grippers in machine and plant engineering, assembly and handling technology and process automation.
| Weight | 0.370000 |
|---|---|
| Manufacturer | Airtec |
| Hersteller-Nr | M 05530HN 24V= |
| EAN | 4050571471002 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
