3/2-Way Solenoid Valve with G 1/8" port and air-spring return (NC). The outlet is closed in the rest position and opens when energized at 230 V AC. Suited to single-acting cylinders and pneumatic control chains.
3/2-Way Solenoid Valve G 1/8", air-spring return (NC), 230 V AC - Airtec M 04310HN 230V
AIRTEC
Original product
Net price (excl. VAT)
€62.25
Item
FL-M-04310HN-230V
Manufacturer no.
M 04310HN 230V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.M 04310HN 230V
EAN4050571470111
Customs tariff number84812090
ConditionNew
Artikel
FL-M-04310HN-230V
The Airtec M 04310HN 230V 3/2-Way Solenoid Valve controls compressed air through a G 1/8" port and is closed in the rest position (NC). The air-spring return (NC) returns the valve to its initial state once the 230 V AC supply is switched off.
Benefits
- Defined rest position through air-spring return (NC), closed without energizing.
- G 1/8" port for direct mounting in compact control assemblies.
- IP 65 protection class allows use in dusty and humid environments.
- Anodized aluminium body with stainless steel and brass internals for long service life.
- Runs on lubricated and non-lubricated, filtered compressed air.
Technical data
| Way function | 3/2-way |
| Actuation | electrical (solenoid coil), air-spring return (NC) |
| Port size | G 1/8" |
| Pressure inlet | port 1 |
| Control voltage | 230 V AC |
| Voltage tolerance | ± 10 % |
| Solenoid coil type | N (connector size 1) |
| Protection class | IP 65 |
| Media | lubricated and non-lubricated, filtered compressed air |
| Body material | anodized aluminium and plastic |
| Internal parts | stainless steel and brass |
| Seal | plastic / NBR |
| Temperature range | -10°C to +70°C |
| Scope of delivery | with solenoid coil and connector |
| Weight | 0.17 kg |
Applications
Control of single-acting cylinders, actuation of blow-off and clamping functions, and general pneumatic switching tasks in machine and fixture building.
All valves of the M series are supplied with solenoid coil and connector as standard. The solenoid coil type is N with connector size 1.
