The 5/3-way solenoid valve controls double-acting cylinders with a defined exhausted mid-position. Port G 1/4", control voltage 230 V AC, protection class IP 65. Suitable for lubricated and unlubricated, filtered compressed air.
5/3-way solenoid valve G 1/4", exhausted mid-position, 230 V AC - Airtec KM 10533HN 230V
AIRTEC
Original product
Net price (excl. VAT)
€119.67
Item
FL-KM-10533HN-230V
Manufacturer no.
KM 10533HN 230V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KM 10533HN 230V
EAN4050571441135
Customs tariff number84812090
ConditionNew
Artikel
FL-KM-10533HN-230V
The Airtec 5/3-way solenoid valve controls double-acting pneumatic cylinders and provides a defined exhausted mid-position. With a G 1/4" port and IP 65 protection class it is suited to continuous industrial operation.
Benefits
- Defined exhausted mid-position. In the mid-position the cylinder ports are exhausted, leaving the piston free to move.
- Housing in anodised aluminium and plastic with stainless steel and brass internal parts.
- Protection class IP 65 for use in dusty and humid environments.
- G 1/4" port for higher flow rates on larger actuators.
- Operates with lubricated and unlubricated, filtered compressed air.
Technical data
| Body | anodised aluminium and plastic |
| Internal parts | stainless steel and brass |
| Seal | NBR |
| Port | G 1/4" |
| Valve function | 5/3-way, mid-position exhausted |
| Control voltage | 230 V AC |
| Voltage tolerance | ± 10 % |
| Protection class | IP 65 |
| Solenoid coil design | N (connector size 1) |
| Pressure inlet | port 1 |
| Media | lubricated and unlubricated, filtered compressed air |
| Temperature range | -10°C to +70°C |
| Weight | 0.55 kg |
Applications
Used to position double-acting cylinders in handling, assembly and automation systems that require a safe intermediate actuator position.
The valve is always supplied with solenoid coil and connector.
| Weight | 0.550000 |
|---|---|
| Manufacturer | Airtec |
| Hersteller-Nr | KM 10533HN 230V |
| EAN | 4050571441135 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
