Manually operated 5/2-way hand lever valve with detent and port G 1/4". The 5/2-way valve controls double-acting cylinders with two detented switching positions. Aluminium body with stainless steel internals for oiled and unoiled compressed air.
5/2-way hand lever valve G 1/4", detent - Airtec HR 14 520
AIRTEC
Original product
Net price (excl. VAT)
€111.25
€93.49
Item
FL-HR-14-520
Manufacturer no.
HR 14 520
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.HR 14 520
EAN4050571360467
Customs tariff number84812090
ConditionNew
Artikel
FL-HR-14-520
The Airtec HR 14 520 is a manually operated 5/2-way hand lever valve with detent and port G 1/4". The 5/2-way valve controls double-acting cylinders with two detented switching positions. The detented actuation locks the switching position mechanically.
Benefits
- Detented hand actuation holds the selected position without continuous force on the lever.
- Port size G 1/4" provides high flow capacity for manual control.
- Aluminium body and spool with stainless steel internals and hand lever for a long service life.
- Pressure inlet possible at any port, which simplifies piping.
- Suitable for oiled and unoiled, filtered compressed air from -10°C to +70°C.
Technical data
| Type | 5/2-way |
| Actuation | hand lever with detent |
| Port | G 1/4" |
| Body and spool | aluminium |
| Internal parts | aluminium, stainless steel |
| Hand lever | stainless steel |
| Seals | POM / NBR |
| Temperature range | -10°C to +70°C |
| Media | oiled and unoiled, filtered compressed air |
| Pressure inlet | possible at any port |
| Weight | 0.55 kg |
Applications
Manual control of cylinders and pneumatic actuators, hand-operated control stations, jig and machine building, maintenance and set-up operation.
| Hersteller-Nr | HR 14 520 |
|---|---|
| Manufacturer | Airtec |
| EAN | 4050571360467 |
| Weight | 0.550000 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
