Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
Makes the assembly of a unit arrangement clean and extendable. The connection is made via thread G 3/4". The inlet pressure covers 2.5 - 10 bar.
Accessory for compressed air equipment, G 3/4", 2.5 - 10 bar, PA 66 GF60, 24 V AC
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€362.12
Item
FL-570591
Manufacturer no.
BEFULL 34 F 24VAC
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.BEFULL 34 F 24VAC
EAN4050571892388
Customs tariff number84812090
ConditionNew
Artikel
FL-570591
Frequently Bought Together
-
This Item:
€362.12
-
Compressed air filter, G 3/8", 1.5 - 16 bar, PA 66 GF60, automatisch
€107.96
-
Safety relief valve G 1/2", factory set and sealed, DN 11, 1.6 bar, stainless steel 1.4404
€375.99
Total price
With this accessory for compressed air equipment an arrangement of units can be built up cleanly and extended later. The inlet pressure extends over 2.5 - 10 bar. The body is made of PA 66 GF60. The device is screwed in with G 3/4". The temperature range extends over -10 to +50 °C.
Benefits
- Degree of protection IP 65 against dust and moisture at the installation point
- Flow rate 9000 l/min without any appreciable pressure drop in the line
- Electrical control with 24 V AC
- Inlet pressure 2.5 - 10 bar as the leading rating of the device
- Connection thread G 3/4" for direct installation in the line
- Temperature range -10 to +50 °C for use in the workshop and in the plant
Technical data
| Property | Value |
|---|---|
| Version | Befülleinheit, elektrisch angesteuert |
| Series | series 4 |
| Thread | G 3/4" |
| Exhaust air thread | G 1/2" |
| Electrical control | 24 V AC |
| Flow rate [l/min] | 9000 |
| H [mm] | 213 |
| H1 [mm] | 102 |
| L [mm] | 170 |
| Inlet pressure [bar] | 2.5 - 10 |
| Body material | PA 66 GF60 |
| Temperature range | -10 to +50 °C |
| Media | oiled and unoiled compressed air, neutral gases |
| Degree of protection | IP 65 |
Applications
Workshop equipment, securing of isolating devices, distribution of compressed air to several outlets.
| Weight | 2.100000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | BEFULL 34 F 24VAC |
| EAN | 4050571892388 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Befülleinheit, elektrisch angesteuert |
| Thread | G 3/4 |
| Flow rate [l/min] | 9000 |
| Befestigungswinkel | W 4 F |
| Series | Futura 4 |
