Mist lubricator, 0 - 16 bar, zinc die casting Z410, plastic bowl with protective cage

This mist lubricator stands at the end of the air treatment and supplies the downstream consumers with oil mist. The device is screwed in with G 1". The inlet pressure extends over 0 - 16 bar. The body is made of zinc die casting Z410. The temperature range extends over -10 to +60 °C.

Benefits

• Connection thread G 1" for direct installation in the line
• Temperature range -10 to +60 °C for use in the workshop and in the plant
• Flow rate 50 - 9000 l/min without any appreciable pressure drop in the line
• Oil reservoir 135 cm³ for long refilling intervals
• Height 220 mm and length 90 mm for installation planning
• Inlet pressure 0 - 16 bar as the leading rating of the device

Applications

Air tools, impact wrenches and chisel hammers, pneumatic drives with a high switching frequency.

Standards and conformity

The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
