2/3 Tube fitting G1x16, swivel nut, lightweight CH type, Brass
2/3 Tube fitting G1x16, swivel nut, lightweight CH type, Brass - Riegler 146197
RIEGLER
Original product
Net price (excl. VAT)
€4.34
Item
RGL-146197
Manufacturer no.
SV1016MS23CH
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SV1016MS23CH
EAN4047322580915
Country of originChina
Customs tariff number74122000
ConditionNew
Artikel
RGL-146197
Frequently Bought Together
-
This Item:
€4.34
-
1/3 Tube fitting - Riegler K1166
As low as €1.58Show details
-
2/3 Tube fitting G1/2x13 swivel nut taper seat heavy-duty, Brass - Riegler 146166
€1.83
Total price
2/3 Tube fitting, G 1 x 16 mm, swivel nut, lightweight CH type, Brass with a bare metal surface
Technical data
| Min. operating pressure | 0 bar |
|---|---|
| Max. operating pressure | 16 bar |
| Max. operating temperature | 100 °C |
| Min. operating temperature | -10 °C |
| Thread | G 1 IT |
| For hose | 16 mm |
| L1 | 42.0 mm |
| a/f | 36 mm |
| L2 | 27.5 mm |
| Material | brass CW614N |
| D | 58.0 mm |
Standards and origin
- Customs tariff number: 74122000
- Country of origin: CN
About Unions
A straight fitting joins tube and threaded port on one axis and is the basic building block of any line layout. Depending on the design, the tube is pushed in or clamped with a union nut. The group covers tube outside diameters from 4 to 12 mm and hose inside diameters from 2 to 10 mm.
What matters when choosing
- Threads are available as male and female from M5 and G 1/8 up to G 1. Adapter versions add thread 1 as a female G 3/4 to G 1 1/4 and thread 2 as the matching male thread.
- Push-in versions follow the tube O.D. from 4 to 12 mm, clamping versions the hose I.D. from 2 to 10 mm. The two figures must not be mixed up.
- The version decides how the joint is handled. A union nut is meant for permanent installation, a knurled nut for connections opened by hand.
- Material follows medium and temperature. Nickel-plated brass and brass CW614N cover general compressed air work, PA, POM and polypropylene lightweight assemblies, and PFA plus stainless steel 1.4571 and 1.4404 chemically loaded runs.
- For the seal, NBR covers standard air, silicone-free NBR paint and coating areas, and FKM or FPM higher temperatures and oil-bearing media.
Typical applications
- Feeding compressed air to cylinders, valves and air preparation units in machine building
- Joining plastic tubing in test rigs and laboratory setups
- Media lines in paint and coating plants using silicone-free seals
- Chemically loaded lines built with PFA or stainless steel fittings
- Vacuum sections on suction grippers that must hold down to -0.98 bar
The material range runs from nickel-plated brass and brass CW614N through PA, POM and polypropylene to perfluoroalkoxy and stainless steels 1.4571 and 1.4404. The operating temperature range of the group is correspondingly wide, from -200 °C to 300 °C.
| Hersteller-Nr | SV1016MS23CH |
|---|---|
| Manufacturer | Riegler |
| Country of Manufacture | China |
| EAN | 4047322580915 |
| Weight | 0.082000 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Temperature (max.) | 100 |
| Material | Brass CW614N |
| Betriebsdruck max [bar] | 16.000000 |
| Pneumatic connection | G1 IG |
| Thread | G 1 IG |
| For hose OD [mm] | 16 |
