Aluminium pipe cutter incl. deburrer, for pipe exterior Ø 4-30 mm - Riegler 114078

Aluminium pipe cutter incl. deburrer, for pipe exterior Ø 4 - 30 mm

Technical data

Standards and origin

• Customs tariff number: 82034000
• Country of origin: DE

About Accessories

This accessory range completes the speedfit and sharkbite compressed air pipe system with the parts that sit between pipe and consumer: screw-in and screw-on supports for the change to threaded ports, air distributor sockets for several outlets, and pipe clamps for fixing the run. The connecting parts work between -0.95 bar and 20 bar.

What matters when choosing

• Thread: R 1/2, R 3/4, G 3/4 and G 1 male for the screw-in supports, G 1/2 and G 3/4 female for the screw-on versions. The mating port on the machine decides which one is needed. Overall length of the supports is between 54 and 80 mm.
• For pipe O.D.: supports and clamps are matched to the pipe in use, with 15, 18, 22 and 28 mm among the sizes covered. The figure has to match the installed pipe exactly.
• Material: brass for the threaded supports, aluminium for the air distributor socket, polypropylene (PP) for the pipe clamps. Each material follows the job of the part.
• Pressure: the connecting parts are rated -0.95 bar to 20 bar, another part of the group carries an operating pressure up to 10 bar. What counts for the design is always the weakest element in the line.
• Operating temperature: -20 °C to 65 °C. The series is not intended for use beyond that, for instance directly downstream of an uncooled compressor.

Typical applications

• Changing over from the push-fit pipe system to threaded ports on machines and air service units
• Setting up take-off points along a compressed air ring main in workshop and production hall
• Splitting the air into several outlets through the distributor socket with G 1/2 or G 3/4 inlet
• Wall mounting of rigid PA and aluminium pipe with pipe clamps
• Extending an existing compressed air installation without soldering or welding

The group holds 31 items for the speedfit and sharkbite series, made in brass, aluminium and polypropylene (PP). Countries of origin are the United Kingdom, Spain, Germany, the Czech Republic and China.
