End distributor, input G 3/4, connection 1 x G 1/2 - Riegler 112616

End distributor, input G 3/4, connection 1 x G 1/2, operat.pressure (air/water) max. 15 bar, ambient temp. 1 °C to 50 °C Made of plastic PA6 GF 30.End and through distributor sockets made of high strength, glass fibre reinforced plastic (PA6 GF 30) with large range of applications. Optionally 1 or up to 3 connection options as well as 2 thread sizes for internal and external threads (cannot be combined). For vertical carrying of media.Universal distributor socket with up to 4 connection options. Suitable for vertical and/or horizontal carrying of media or the secure connection(avoidance of existing components) of pressure reducer or maintenance device, for example.All distributor sockets have a durable brass threaded insert, whose shape secures it against rotation and against axial shift due to its shape.Suitable for media compressed air (ambient temperature -10 °C to 50 °C) or water (ambient temperature 1 °C to 50 °C). Drilling diagram dimensions are identical for all distributor sockets, so a simpler and more flexible exchange between end, through and universal distributor sockets is ensured.Caution:Note that the distributor sockets should not be installed in danges zones. Danger zones are, for example, transport routes, escape routes, etc.

Technical data

Standards and origin

• Customs tariff number: 84818099
• Country of origin: DE

About Porting boxes

A distribution box takes a compressed air or water line and passes it on to several outlets, sparing you a manifold built from individual fittings. The glass fibre reinforced PA6 GF 30 body is screwed straight to a wall or frame through its mounting hole. All 13 items work up to 15 bar operating pressure.

What matters when choosing

• Version: with or without a through thread. The through distributor sits in a line that continues, the end distributor terminates it.
• Number of ports: the samples show 1 to 4 outlets in G 1/2. That decides how many draw-off points hang on one box.
• Inlet thread: G 1/2 or G 3/4 to suit the supply line. On the through distributor the same size applies to inlet and outlet.
• Material: glass fibre reinforced PA6 GF 30 with brass threads, for which a separate tightening torque is given.
• Operating pressure up to 15 bar on air and water, with ambient temperature stated as 1 °C to 50 °C. The box is therefore not intended for areas at risk of frost.

Typical applications

• Compressed air draw-off points in workshops and assembly lines
• Distribution of cooling and service water around machinery
• Ring mains where the box acts as a through distributor
• Retrofitting extra outlets onto existing pipework
• Wall mounting at workstations that need a fixed tapping point

All 13 items are made of high strength glass fibre reinforced PA6 GF 30 and come from German production.
