Distributor strip 10 integrated ball valves, In/output G 3/8 - Riegler 103580

Distributor strip 10 integrated ball valves, Die-cast aluminium, PN max 10 bar rough vacuum, Temp. -10°C to 100°C, In/output G 3/8 Distributor and isolator block for machines and installations where it is necessary to close individual circuits. This block contains 6, 8 or 10 ball valves that can be adjusted using a screwdriver.

Technical data

Standards and origin

• Customs tariff number: 84818081
• Country of origin: AT

About Distributor blocks

Distributor strips take compressed air from one inlet to several outlets and save you building the same thing from separate tees and nipples. The maximum operating pressure is stated as 10 bar, with inlets from G 1/8 to G 1/2. The group covers 39 items with varying outlet counts.

What matters when choosing

• Thread 1: the inlet comes as G 1/8, G 1/4, G 3/8 or G 1/2 female. Size it by the supply line and by the total air demand of all outlets together.
• Thread 2: outlets are M5, G 1/8 or G 1/4 female and must match the push-in connectors or fittings on your control lines.
• Number of outlets: strips are available with 2, 3, 4 or 6 outlets, on one side or on both, and in versions with 6, 8 or 10 integrated ball valves. Shut-off outlets pay off wherever single control circuits need to be isolated for servicing.
• Max. operating pressure: 10 bar, which keeps the range within normal shop air supply.
• Material: die-cast aluminium with an NBR O-ring seal, keeping the strip light where it is mounted on the machine frame.

Typical applications

• Distributing control air within a machine frame to several valves and cylinders
• Isolating individual control circuits during maintenance and fault finding via the integrated ball valves
• Setting up several compressed air take-off points at assembly and test stations
• Adding further consumers to an existing supply line
• Building compact connection blocks inside a control cabinet or behind panelling

The listed material is die-cast aluminium with an NBR O-ring, and the ball valve versions carry a stated temperature range of -10 °C to 100 °C. The 39 items are produced in Italy and Austria.
