Adds mounting and connection to the air treatment unit. The connection is made via thread G 1/2". The material used is zinc die casting Z410.
Distribution block, G 1/2", zinc die casting Z410, series 2, temperature range -10 to +60 °C
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€42.94
Item
FL-015714
Manufacturer no.
VB CL 12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VB CL 12
EAN4050571718879
Customs tariff number84818099
ConditionNew
Artikel
FL-015714
Frequently Bought Together
-
This Item:
€42.94
-
Safety relief valve G 3/4", factory set and sealed, DN 16, 40 bar, stainless steel 1.4404
€528.00
-
Combined air service unit, G 3/4", 0.5 - 12 bar, inlet 1.5 - 12 bar
€337.39
Total price
With this distribution block an arrangement of units can be built up cleanly and extended later. The temperature range extends over -10 to +60 °C. The body is made of zinc die casting Z410. The device is screwed in with G 1/2". The media provided for are oiled and unoiled compressed air, neutral gases.
Benefits
- Version according to Richtlinie 2014/34/EU
- Material zinc die casting Z410 determines strength and resistance of the part
- Released for oiled and unoiled compressed air, neutral gases
- Connection thread G 1/2" for direct installation in the line
- Temperature range -10 to +60 °C for use in the workshop and in the plant
Technical data
| Property | Value |
|---|---|
| Series | series 2 |
| Design | standard |
| Thread P/A (inlet/outlet) | G 1/2" |
| Threaded outlet B (top) | G 1/2" |
| Threaded outlet C (bottom) | G 1/2" |
| Threaded outlet D (front/rear) | G 1/4" |
| Flow rate P-A [l/min] | 11000 |
| Flow rate P-B [l/min] | 8750 |
| Flow rate P-C [l/min] | 8750 |
| Flow rate P-D [l/min] | 1300 |
| L1 / L2 [mm] | 69 |
| Mounting bracket | available as an accessory |
| Connecting kit for the standard design | available as an accessory |
| Connecting kit for the narrow design | available as an accessory |
| Body material | zinc die casting Z410 |
| Temperature range | -10 to +60 °C |
| Media | oiled and unoiled compressed air, neutral gases |
| Standards | Richtlinie 2014/34/EU |
Applications
Machine and plant construction, mounting of air treatment units, retrofitting and conversion of existing installations.
Standards and conformity
The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
| Weight | 0.700000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | VB CL 12 |
| EAN | 4050571718879 |
| Zolltarifnummer | 84818099 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Standard |
| Befestigungswinkel | W 2 |
| Series | Multifix 2 |
