Mist lubricator, G 1/4", 0 - 16 bar, zinc die casting Z410, plastic bowl, series 1, 48

Where moving parts need permanent lubrication, this mist lubricator meters the oil straight into the air stream. The inlet pressure extends over 0 - 16 bar. The body is made of zinc die casting Z410. The device is screwed in with G 1/4". The temperature range extends over -10 to +60 °C.

Benefits

• Flow rate 26 - 1500 l/min without any appreciable pressure drop in the line
• Oil reservoir 50 cm³ for long refilling intervals
• Height 167 mm and length 48 mm for installation planning
• Inlet pressure 0 - 16 bar as the leading rating of the device
• Connection thread G 1/4" for direct installation in the line
• Temperature range -10 to +60 °C for use in the workshop and in the plant

Applications

Plants with long operating times, pneumatic motors and vibrators, feeding and clamping technology.

Standards and conformity

The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
