Reduces the inlet pressure to the value the consumer really needs. The connection is made via thread G 1/4". The pressure setting range covers 0.2 - 6 bar.
Gauge mounted regulator, G 1/4", 0.2 - 6 bar, zinc die casting Z410, series 1
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€122.00
Item
FL-032103
Manufacturer no.
MANOREG R 14-6
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MANOREG R 14-6
EAN4050571480004
Customs tariff number84811099
ConditionNew
Artikel
FL-032103
Frequently Bought Together
-
This Item:
€122.00
-
Safety valve, preset and lead-sealed, G 3/4", DN 10, 6.60 bar, brass
€45.61
-
Bimetal thermometer, horizontal, chemical version, dial 100 mm, 0 to +400 °C, stem 63 mm
€294.83
Total price
This gauge mounted regulator reduces the line pressure to the value the downstream tool actually needs. The pressure setting range extends over 0.2 - 6 bar. The body is made of zinc die casting Z410. The device is screwed in with G 1/4". The temperature range extends over -10 to +60 °C.
Benefits
- Flow rate 2100 l/min without any appreciable pressure drop in the line
- Height 134 mm and length 48 mm for installation planning
- Version according to Richtlinie 2014/34/EU
- Pressure setting range 0.2 - 6 bar as the leading rating of the device
- Connection thread G 1/4" for direct installation in the line
- Temperature range -10 to +60 °C for use in the workshop and in the plant
Technical data
| Property | Value |
|---|---|
| Series | series 1 |
| Thread | G 1/4" |
| Pressure setting range [bar] | 0.2 - 6 |
| Flow rate [l/min] | 2100 |
| Gauge indication [bar] | 0 - 10 |
| Connecting kit | available as an accessory |
| D [mm] | 54 |
| H [mm] | 134 |
| H1 [mm] | 107 |
| L [mm] | 48 |
| Panel thread | M 48x1.5 |
| Body material | zinc die casting Z410 |
| Temperature range | -10 to +60 °C |
| Media | oiled and unoiled compressed air, neutral gases |
| Standards | Richtlinie 2014/34/EU |
Applications
Plant construction with fluctuating line pressure, packaging machines, conveying technology and maintenance.
Standards and conformity
The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
| Weight | 0.500000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | MANOREG R 14-6 |
| EAN | 4050571480004 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Flow rate [l/min] | 2100 |
| Druckregelbereich [bar] | 0,2 - 6 |
| Manometeranzeige [bar] | 0 - 10 |
| Series | Multifix 1 |
