Keeps the working pressure constant even when the line pressure fluctuates. The pressure setting range covers 0.2 - 6 bar. The connection is made via thread G 1/2".
Pressure regulator, G 1/2", 0.2 - 6 bar, zinc die casting Z410, series 2, flow rate 8500 l/min
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€87.06
Item
FL-036912
Manufacturer no.
RB 12-6
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RB 12-6
EAN4050571570736
Customs tariff number84811099
ConditionNew
Artikel
FL-036912
Frequently Bought Together
-
This Item:
€87.06
-
Digital pressure gauge, G 1/2", 0 - 1000 bar, plastic, accuracy class 0.5, protection IP 65
€954.87
-
Pressure gauge, vertical version, G 1/2", 160 mm, 0 - 400 bar, 1.4301, accuracy class 1
€160.38
Total price
A steady working pressure saves compressed air and protects the consumers, the pressure regulator provides it. The body is made of zinc die casting Z410. The device is screwed in with G 1/2". The pressure setting range extends over 0.2 - 6 bar. The temperature range extends over -10 to +60 °C.
Benefits
- Version according to Richtlinie 2014/34/EU
- Pressure setting range 0.2 - 6 bar as the leading rating of the device
- Connection thread G 1/2" for direct installation in the line
- Temperature range -10 to +60 °C for use in the workshop and in the plant
- Flow rate 8500 l/min without any appreciable pressure drop in the line
- Height 135 mm and length 69 mm for installation planning
Technical data
| Property | Value |
|---|---|
| Series | series 2 |
| Inlet thread | G 1/2" |
| Outlet thread | G 1/2" |
| Pressure setting range [bar] | 0.2 - 6 |
| Gauge indication [bar] | 0 - 10 |
| Flow rate [l/min] | 8500 |
| Mounting bracket | available as an accessory |
| Mounting bracket with panel nut | available as an accessory |
| Connecting kit | available as an accessory |
| H [mm] | 135 |
| H1 [mm] | 100 |
| L [mm] | 69 |
| Panel thread | M 50x1.5 |
| Body material | zinc die casting Z410 |
| Temperature range | -10 to +60 °C |
| Media | oiled and unoiled compressed air, neutral gases |
| Scope of delivery | pressure regulator including pressure gauge |
| Standards | Richtlinie 2014/34/EU |
Applications
Assembly lines and manual workstations, pneumatic drives, painting and cleaning technology, laboratory supply.
Standards and conformity
The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
| Weight | 0.900000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | RB 12-6 |
| EAN | 4050571570736 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Flow rate [l/min] | 8500 |
| Druckregelbereich [bar] | 0,2 - 6 |
| Manometeranzeige [bar] | 0 - 10 |
| Befestigungswinkel | W 2 |
| Series | Multifix 2 |
