Supplies clean compressed air at the set pressure to the tool. The device is screwed in with G 1/8". The pressure setting range extends over 0.5 - 10 bar.
Filter regulator, 0.5 - 10 bar, zinc die casting Z410, plastic bowl, G 1/8"
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€54.67
Item
FL-004015
Manufacturer no.
FD 00
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.FD 00
EAN4050571293383
Customs tariff number84811005
ConditionNew
Artikel
FL-004015
Frequently Bought Together
-
This Item:
€54.67
-
Accessory for compressed air equipment, G 3/4", 2.5 - 10 bar, PA 66 GF60, 24 V AC
€362.12
-
Bimetal thermometer, horizontal, case 160 mm, range 0 to +80 °C, stem 63 mm
€116.02
Total price
This filter regulator treats the compressed air and controls the working pressure in a single step. The material used is zinc die casting Z410. The pressure setting range covers 0.5 - 10 bar. The connection is made via thread G 1/8". The inlet pressure amounts to 1.5 - 16 bar.
Benefits
- Inlet pressure 1.5 - 16 bar, so the load limit is clearly stated
- Temperature range -10 to +60 °C for use in the workshop and in the plant
- Version according to ISO 8573-1
- Version according to Richtlinie 2014/34/EU
- Pressure setting range 0.5 - 10 bar as the leading rating of the device
- Connection thread G 1/8" for direct installation in the line
Technical data
| Property | Value |
|---|---|
| Thread | G 1/8" |
| Pressure setting range [bar] | 0.5 - 10 |
| Bowl version | plastic bowl |
| Condensate drain | semi-automatic |
| Gauge indication [bar] | 0 - 16 |
| Inlet pressure [bar] | 1.5 - 16 |
| Body material | zinc die casting Z410 |
| Temperature range | -10 to +60 °C |
| Media | compressed air, neutral gases |
| Scope of delivery | filter regulator including 40 mm pressure gauge |
| Standards | ISO 8573-1, Richtlinie 2014/34/EU |
Applications
Pneumatic controls, packaging and conveying technology, workshop supply and retrofitting on older plants.
Standards and conformity
The data sheets refer to ISO 8573-1, Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
| Weight | 0.320000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | FD 00 |
| EAN | 4050571293383 |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Behälterausführung | Kunststoffbehälter |
| Thread | G 1/8 |
| Condensate drain | semi-automatic |
| Druckregelbereich [bar] | 0,5 - 10 |
| Manometeranzeige [bar] | 0 - 16 |
| Befestigungswinkel | WHM 30 |
| Operating conditions | ISO 8573-1 |
