Pressure gauge, horizontal version, G 1/2", 100 mm, 0 - 250 mbar, 1.4301, accuracy class 1.6

The pressure gauge shows the pressure in a line, vessel or device without auxiliary power. Case and measuring system are made of 1.4301 and copper alloy. The connection is made via G 1/2", the diameter comes to 100 mm. The indicating range extends over 0 - 250 mbar. The temperature range extends over -20 to +60 °C.

Benefits

• Degree of protection IP 54 against dust and moisture at the installation point
• Indicating range 0 - 250 mbar with a scale division of 5 mbar
• Connection thread G 1/2" for direct installation in the line
• Nominal size 100 mm for reliable reading from a distance
• Accuracy class 1.6 as the limit of the permissible measuring deviation
• Temperature range -20 to +60 °C for use in the workshop and in the plant

Applications

Monitoring of pumps and filters, acceptance and repeat tests, setting of regulators and valves.
