Coupling nipple TLX 1/2", flat-face, female thread G 1/2", 420 bar, steel - Cejn 105076205
Joins hose and machine through the female G 1/2" thread. The flat-face part from series 507 carries 420 bar working pressure when connected.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Built for hydraulic circuits with high surge flow and hard pressure impulses. The TLX coupling nipple in size 1/2" runs up to 420 bar connected and reaches a minimum burst pressure of 1680 bar. It is fitted through the female G 1/2" thread.
Benefits
- Steel body of the TLX range with zinc-nickel surface treatment.
- Female G 1/2" thread for a direct port connection in size 1/2".
- Size 1/2" matches series 507 of the TLX range.
- Screw-to-connect instead of push-to-connect, developed for high flow and pressure impulses.
Applications
For hydraulic circuits on construction and demolition equipment where high flow and repeated pressure peaks meet.
Technical data
| Component | Nipple |
|---|---|
| Version | Female thread |
| Size (inch) | 1/2" |
| Connection type | Flat-face screw coupling |
| Connection | G 1/2" |
| Main material | Steel |
| Max. working pressure, connected | 420 bar |
| Min. burst pressure, connected | 1680 bar |
| Packaging unit | 1 piece |
| Manufacturer | Cejn |
| Hersteller-Nr | 105076205 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | CEJN-Product GmbH, Junkersring 16, DE-53844 Troisdorf, www.cejn.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
Downloads
Datasheet
CAD Data
