Fine filter, G 3/4", 1.5 - 16 bar, PA 66 GF60, metal bowl with sight glass

Clean compressed air extends the service life of valves and cylinders, and this fine filter provides it. The inlet pressure extends over 1.5 - 16 bar. The body is made of PA 66 GF60. The device is screwed in with G 3/4". The temperature range extends over -10 to +50 °C.

Benefits

• Flow rate 1500 l/min without any appreciable pressure drop in the line
• Condensate capacity up to 87 cm³ between two drains
• Height 255 mm and length 85 mm for installation planning
• Inlet pressure 1.5 - 16 bar as the leading rating of the device
• Connection thread G 3/4" for direct installation in the line
• Temperature range -10 to +50 °C for use in the workshop and in the plant

Applications

Water and oil circuits, cooling systems, cleaning of process media and maintenance.

Standards and conformity

The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
