The clamping unit holds the piston rod in any position. The underlying rating is a piston diameter of 80 mm. The dimensions come to 110 x 100 x 105 mm.
Clamping unit for cylinders ISO 15552, holding force 5,000 N, for piston diameter 80 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€718.53
€603.81
Item
FL-049278
Manufacturer no.
XL 80 BREMS
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.XL 80 BREMS
EAN4050571800116
Customs tariff number84123100
ConditionNew
Artikel
FL-049278
Frequently Bought Together
-
This Item:
€718.53 €603.81
-
Clamping unit for cylinders ISO 15552, holding force 7,500 N, for piston diameter 125 mm
€1,163.25 €977.52
-
Clamping unit for cylinders ISO 15552, holding force 1,000 N, for piston diameter 40 mm
€320.87 €269.64
Once installed, the clamping unit holds the piston rod in any position. Decisive for the selection is a piston diameter of 80 mm.
Benefits
- Matched to cylinders with a 80 mm piston diameter.
- The static holding force comes to 5,000 N.
- Holding on power failure needs no auxiliary energy, releasing takes an operating pressure of 4 - 10 bar.
- The temperature range covers -20 to +80 °C.
- Piston diameter of 80 mm as per the data sheet.
- Produced to ISO 15552.
Technical data
| Version | complete clamping unit |
|---|---|
| Piston diameter [mm] | 80 |
| Piston rod diameter (f8 / h9) [mm] | 25 |
| Holding force (static) [N] | 5,000 |
| Required extension of the cylinder piston rod [mm] | 80 |
| Dimension A1 [mm] | 72.0 |
| Dimension A2 [mm] | 70 |
| Dimension A3 [mm] | 10.0 |
| Dimension A4 [mm] | 44 |
| Dimension B [mm] | 100 |
| Dimension C [mm] | 105 |
| Dimension D1 [mm] | 45 |
| Dimension D2 [mm] | 48 |
| Dimension D4 [mm] | 11.0 |
| Dimension F [mm] | 52.5 |
| Thread G1 | M 10 |
| Thread G2 | M 8 |
| Dimension L1 [mm] | 16 |
| Dimension L2 [mm] | 58 |
| Dimension L3 [mm] | 16 |
| Dimension L5 [mm] | 90 |
| Dimension L6 [mm] | 110 |
| Dimension L7 [mm] | 62.0 |
| Dimension L8 [mm] | 28.0 |
| Dimension L9 [mm] | 35.5 |
| Dimension L10 [mm] | 16 |
| Temperature range [°C] | -20 to +80 |
| Working pressure [bar] | 4 - 10 |
| Scope of delivery | clamping unit incl. fixing screws |
Applications
In machine and plant construction the clamping unit holds a cylinder with a 80 mm piston diameter in place.
Standards and conformity
The interface dimensions are based on ISO 15552.
| Norm | ISO 15552 |
|---|---|
| Hersteller-Nr | XL 80 BREMS |
| Manufacturer | Fluidics equipment |
| EAN | 4050571800116 |
| Weight | 2.300000 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
