This clevis swivel mounting holds the cylinder and carries its forces into the machine frame. A key figure is a piston diameter of 63 mm. Size 190 x 75 x 51 mm, material aluminium.
Spherical clevis swivel mounting ISO 15552, for piston diameter 63 mm, aluminium
FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€27.79 €23.35
Item FL-048050
Manufacturer no. TQ 63
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TQ 63
EAN4050571701123
Customs tariff number76169990
ConditionNew
Artikel
FL-048050
Frequently Bought Together
- This Item: €27.79 €23.35
- Spherical clevis swivel mounting ISO 15552, for piston diameter 200 mm, aluminium €213.80 €179.66
- Spherical clevis swivel mounting ISO 15552, for piston diameter 32 mm, aluminium €17.55 €14.75
As a clevis swivel mounting the article holds the cylinder and carries its forces into the machine frame. The data state a piston diameter of 63 mm. This version is listed with 190 mm for dimension L, 75 mm for dimension M and 51 mm for dimension A. Material aluminium is listed for this version.
Benefits
- Designed for cylinders with a 63 mm piston diameter to ISO 15552.
- Interface dimensions to ISO 15552 allow a replacement without changing the machine.
- Material aluminium for size 63 mm.
- Dimension A comes to 51 mm for size 63 mm.
- Dimension R comes to 25 mm for size 63 mm.
Technical data
| Material | aluminium |
|---|---|
| For piston diameter [mm] | 63 |
| Dimension A [mm] | 51 |
| Dimension B [mm] | 21 |
| Dimension D [mm] | 16 |
| Dimension E [mm] | 9.0 |
| Dimension F [mm] | 32 |
| Dimension H [mm] | 11 |
| Dimension L [mm] | 190 |
| Dimension M [mm] | 75 |
| Dimension N [mm] | 56.5 |
| Dimension R [mm] | 25 |
| Scope of delivery | 1 swivel mounting incl. 4 fixing screws |
Applications
On feed and infeed units the spherical clevis swivel mounting carries the cylinder of size 63 mm.
Standards and conformity
Made to ISO 15552 and matched to a piston diameter of 63 mm.
| Hersteller-Nr | TQ 63 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571701123 |
| Weight | 0.175000 |
| Zolltarifnummer | 76169990 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
