The swivel eye mounting holds the cylinder and carries its forces into the machine frame. The underlying rating is a cylinder diameter of 40 mm. 28 x 41.6 x 12 mm in stainless steel 1.4404.
Swivel eye mounting for round cylinders ISO 6431, for cylinder diameter 40 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€311.77
Item
FL-021186
Manufacturer no.
TGR 40 ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TGR 40 ES
EAN4050571695033
Customs tariff number84129080
ConditionNew
Artikel
FL-021186
Once installed, the swivel eye mounting holds the cylinder and carries its forces into the machine frame. Decisive for the selection is a cylinder diameter of 40 mm.
Benefits
- Designed for round cylinders with a 40 mm cylinder diameter to ISO 6431.
- Material stainless steel 1.4404 for a cylinder diameter of 40 mm.
- Dimension B comes to 28 mm for size 40 mm.
- Dimension C comes to 41.6 mm for size 40 mm.
- Dimension D comes to 12 mm for size 40 mm.
Technical data
| Material | stainless steel 1.4404 |
|---|---|
| For cylinder diameter [mm] | 40 |
| Dimension B [mm] | 28 |
| Dimension C [mm] | 41.6 |
| Dimension D [mm] | 12 |
| Dimension E [mm] | 160 |
| Dimension F [mm] | 15 |
| Dimension N [mm] | 32 |
Applications
In machine and plant construction the swivel eye mounting holds a cylinder with a 40 mm piston diameter in place.
Standards and conformity
The interface dimensions are based on ISO 6431.
| Weight | 0.195000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | TGR 40 ES |
| EAN | 4050571695033 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 6431 |
