This swivel eye mounting holds the cylinder and carries its forces into the machine frame. A key figure is a piston diameter of 80 mm. Size 86 x 63 x 47 mm, material burnished steel.
90 degree swivel eye mounting ISO 15552, for piston diameter 80 mm, burnished steel
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€64.81
Item
FL-438895
Manufacturer no.
TD 80 ST
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TD 80 ST
EAN4050571872946
Customs tariff number73269098
ConditionNew
Artikel
FL-438895
Frequently Bought Together
-
This Item:
€64.81
-
90 degree swivel eye mounting ISO 15552, for piston diameter 100 mm, burnished steel
€78.81
-
90 degree swivel eye mounting ISO 15552, for piston diameter 200 mm, aluminium
€299.15
Total price
As a swivel eye mounting the article holds the cylinder and carries its forces into the machine frame. This version comes with 86 mm for dimension M, 63 mm for dimension H and 47 mm for dimension G.
Benefits
- Designed for cylinders with a 80 mm piston diameter to ISO 15552.
- Interface dimensions to ISO 15552 allow a replacement without changing the machine.
- Material burnished steel for size 80 mm.
- Dimension H comes to 63 mm for size 80 mm.
- Dimension W1 comes to 40 mm for size 80 mm.
- Dimension W2 comes to 60 mm for size 80 mm.
Technical data
| Material | burnished steel |
|---|---|
| For piston diameter [mm] | 80 |
| Dimension B [mm] | 50 |
| Dimension D [mm] | 16 |
| Dimension G [mm] | 47 |
| Dimension H [mm] | 63 |
| Dimension K [mm] | 14 |
| Dimension M [mm] | 86 |
| Dimension N [mm] | 66 |
| Dimension S [mm] | 11.0 |
| Dimension W1 [mm] | 40 |
| Dimension W2 [mm] | 60 |
Applications
In handling and clamping equipment the 90 degree swivel eye mounting transfers the forces of the 80 mm cylinder into the frame.
Standards and conformity
The main dimensions follow ISO 15552 and therefore suit any cylinder of this size.
| Norm | ISO 15552 |
|---|---|
| Hersteller-Nr | TD 80 ST |
| Manufacturer | Fluidics equipment |
| EAN | 4050571872946 |
| Weight | 0.800000 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
