The swivel eye mounting holds the cylinder and carries its forces into the machine frame. The underlying rating is a piston diameter of 63 mm. 67 x 50 x 37 mm in burnished steel.
90 degree swivel eye mounting ISO 15552, for piston diameter 63 mm, burnished steel
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€58.94
Item
FL-438894
Manufacturer no.
TD 63 ST
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TD 63 ST
EAN4050571872939
Customs tariff number73269098
ConditionNew
Artikel
FL-438894
Once installed, the swivel eye mounting holds the cylinder and carries its forces into the machine frame. This version is listed with 67 mm for dimension M, 50 mm for dimension H and 37 mm for dimension G. The stated figure is a piston diameter of 63 mm.
Benefits
- Designed for cylinders with a 63 mm piston diameter to ISO 15552.
- Interface dimensions to ISO 15552 allow a replacement without changing the machine.
- Material burnished steel for size 63 mm.
- Dimension H comes to 50 mm for size 63 mm.
- Dimension W1 comes to 35 mm for size 63 mm.
- Dimension W2 comes to 50 mm for size 63 mm.
Technical data
| Material | burnished steel |
|---|---|
| For piston diameter [mm] | 63 |
| Dimension B [mm] | 40 |
| Dimension D [mm] | 16 |
| Dimension G [mm] | 37 |
| Dimension H [mm] | 50 |
| Dimension K [mm] | 12 |
| Dimension M [mm] | 67 |
| Dimension N [mm] | 52 |
| Dimension S [mm] | 9.0 |
| Dimension W1 [mm] | 35 |
| Dimension W2 [mm] | 50 |
Applications
In handling and clamping equipment the 90 degree swivel eye mounting transfers the forces of the 63 mm cylinder into the frame.
Standards and conformity
The main dimensions follow ISO 15552 and therefore suit any cylinder of this size.
| Weight | 0.500000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | TD 63 ST |
| EAN | 4050571872939 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552 |
