The auto-nipple DN 8 works in cooling circuits of machine tools and is rated for 35 bar. Flat-face, non-drip design, which keeps the connection leak-free. Max. working pressure 35 bar, connection and disconnection under full working pressure.
Auto-nipple, flat-face, M28x1.5, DN 8, 35 bar, brass, series 944 - Cejn 109446554
CEJN
Original product
Net price (excl. VAT)
€162.27
Item
CEJ-109446554
Manufacturer no.
109446554
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.109446554
Customs tariff number84812010
ConditionNew
Artikel
CEJ-109446554
The auto-nipple DN 8 works in cooling circuits of machine tools and is rated for 35 bar.
Benefits
- Flat-face, non-drip design, which keeps the connection leak-free.
- Max. working pressure 35 bar, connection and disconnection under full working pressure.
- Nominal flow diameter 8 mm at connection M28x1.5.
- Main material brass, listed by the manufacturer as nickel-plated brass.
- For installation in manifolds, so many lines can be parted at the same time.
Technical data
| Type | Auto-nipple |
|---|---|
| Connection type | Flat-face auto couplings |
| Connection | M28x1.5 |
| Nominal flow diameter | 8 mm |
| Max. working pressure | 35 bar |
| Main material | Brass |
| Seal material | NBR |
| Series | 944 |
| Packaging unit | 1 piece |
Applications
It is intended for fluid and cooling applications such as tool-changing systems on machine equipment. Built into manifolds, several media lines are coupled at the same time.
Material and series
The manufacturer lists the nominal flow diameter 8 mm as series 944. Main material brass. Seal material NBR. The flat-face, non-drip design is the hallmark of the Cejn auto-couplings.
| Manufacturer | Cejn |
|---|---|
| Hersteller-Nr | 109446554 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | CEJN-Product GmbH, Junkersring 16, DE-53844 Troisdorf, www.cejn.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
