Water leak detector WLD2 PoE, 4 zones up to 185 m each, LAN and WiFi, SNMP, plain unit - HW group 600717

When you watch raised floors, cooling lines or CRAC units in a data center, a leak alarm is only useful if it tells you where the water is. The WLD2 splits monitoring into up to 4 zones, each with up to 185 m of cable, and reports OK, flooded or cable fault separately for every zone.

Benefits

• Find the leak faster: 4 separate zones of up to 185 m each, with a different phone number per zone if needed.
• Fits existing monitoring via SNMP, SNMP trap and XML, plus HWg-Push to SensDesk portals.
• Flexible networking: Ethernet 10/100 Mbit and 2.4 GHz WiFi (b/g/n) usable at the same time, WiFi with external antenna for extended range.
• One cable for data and power: PoE supply at 15 mA, or an external 5 V adapter.
• Higher reliability: damaged or disconnected sensing cables are reported as a cable fault.
• Local action over the network: Box2Box switches relay outputs on Poseidon2 or Damocles2, for example to sound a siren.

Applications

• Data centers and server rooms, sensing cable under the raised floor
• Liquid cooling with CDUs and quick disconnects, cable routed along the lines
• Leaking pipes, cable wrapped around the pipe
• Drip trays and air-conditioning outlets
• Protection against water entering through skylights, cable along the walls

Compatibility

• WLD sensing cable type A and B, e.g. packages with connecting cable HW group 600417, 600467, 600468
• Poseidon2 and Damocles2 for Box2Box relay actions
• HW group SMS gateways for SMS and voice calls
• HWg-cloud.com and SensDesk.com portals
