ROTEX GS 38 Intermediate Tube ZR3 LR 3529 mm with 2 Bonded Hubs - KTR 550380943529

KTR ✓ Original product Brand new Made in Germany

Bridges the shaft gap without backlash: ROTEX GS 38 intermediate tube ZR3 with a 3529 mm tube length LR and two bonded hubs. For servo hydraulics, test benches and automation that demand accurate positioning.

Net
€1,092.08
excl. VAT
Item KTR-550380943529
Manufacturer no. 550380943529
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For drives with a shaft gap, KTR supplies the ROTEX GS 38 as a ZR3 intermediate tube, here with a tube length LR of 3529 mm. The coupling works torsionally flexible and backlash-free because the spider is held with pre-tension between the hub jaws.

Benefits

  • Bridges the gap between the shaft ends with LR 3529 mm
  • Tube and both hubs are bonded together
  • Backlash-free on reversing thanks to the pre-tensioned teeth
  • Axial, radial and angular misalignment compensation

Applications

Typical fields are servo hydraulics, test bench technology and automation, wherever backlash-free operation and positioning accuracy count. Check dimensions and the combination with hubs and spider for size 38 against the KTR dimension sheet before ordering.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR3529 mm
HS code84839089
KTR article no.550380943529
Weight0.71 kg
Hersteller-Nr550380943529
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure
