ROTEX GS 38 Spare Spider 92 Sh-A-GS yellow for Servo Coupling - KTR 550381000001

KTR ✓ Original product Brand new Made in Germany

92 Sh-A-GS spider in yellow for the backlash-free ROTEX GS 38 servo coupling. Its Shore hardness sets stiffness and damping, and the convex teeth sit under pre-tension in the hubs to keep the drive free of backlash.

Net
€13.30
excl. VAT
Item KTR-550381000001
Manufacturer no. 550381000001
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Replacement or tuning: the ROTEX GS 38 spider in 92 Sh-A fits the hubs of the same size. The principle of the series: the spider sits under pre-tension in the hub jaws and transmits torque without play.

Benefits

  • Shore hardness 92 Sh-A as the key value for stiffness and damping
  • Convex teeth fitted under pre-tension for backlash-free running
  • Stiffness and damping matched through different spider hardnesses
  • Compensates angular, radial and axial shaft misalignment
  • Low component weight of 0.05 kg

Applications

Users fit the coupling in servo hydraulics, test bench technology and automation, where reversal backlash would cost accuracy. Matching hubs and spiders of the same size 38 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentSpider
Hardness92 Sh-A-GS
Colouryellow
Weight0.05 kg
HS code84839089
KTR article no.550381000001
Hersteller-Nr550381000001
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Shore hardness92 Sh-A

Downloads

Datasheet

User Manual

Catalogue

Brochure

Accessories

Alternatives

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
