ROTEX GS 38 Intermediate Tube ZR3 LR 3060 mm with 2 Bonded Hubs - KTR 550380943060

KTR ✓ Original product Brand new Made in Germany

Zero backlash over distance: ROTEX GS 38 intermediate tube ZR3 with a 3060 mm tube length LR and two bonded hubs. The pre-tensioned spider transmits torque without play and compensates shaft misalignment.

Net
€1,000.59
excl. VAT
Item KTR-550380943060
Manufacturer no. 550380943060
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For drives with a shaft gap, KTR supplies the ROTEX GS 38 as a ZR3 intermediate tube, here with a tube length LR of 3060 mm. KTR designs the ROTEX GS as a backlash-free, torsionally flexible servo coupling whose spider is fitted under pre-tension.

Benefits

  • Tube length LR 3060 mm as a fixed dimension for the shaft gap
  • Supplied with 2 bonded hubs as a ready-to-fit unit
  • Backlash-free torque transmission through the pre-tensioned spider
  • Takes up angular, radial and axial misalignment in the drive train

Applications

Typical fields are servo hydraulics, test bench technology and automation, wherever backlash-free operation and positioning accuracy count. Matching hubs and spiders of the same size 38 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR3060 mm
HS code84839089
KTR article no.550380943060
Weight0.71 kg
Hersteller-Nr550380943060
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
