ROTEX GS 38 Intermediate Tube ZR3 LR 602 mm with 2 Bonded Hubs - KTR 550380940602

KTR ✓ Original product Brand new Made in Germany

Backlash-free connection across a shaft gap: ROTEX GS 38 intermediate tube ZR3 with a 602 mm tube length LR and two bonded hubs. Compensates angular, radial and axial misalignment and stays backlash-free thanks to the pre-tensioned spider.

Net
€543.67
excl. VAT
Item KTR-550380940602
Manufacturer no. 550380940602
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Where input and output are apart, the ROTEX GS 38 intermediate tube ZR3 with LR 602 mm closes the gap. A pre-tensioned spider with convex teeth sits in the concave jaws of the hubs and keeps the connection free of backlash.

Benefits

  • Defined tube length LR 602 mm, no cutting to length required
  • Two hubs already bonded to the tube, which saves assembly steps
  • Backlash-free torque transmission through the pre-tensioned spider
  • Axial, radial and angular misalignment compensation

Applications

Typical fields are servo hydraulics, test bench technology and automation, wherever backlash-free operation and positioning accuracy count. Matching hubs and spiders of the same size 38 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR602 mm
HS code84839089
KTR article no.550380940602
Weight0.71 kg
Hersteller-Nr550380940602
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure
