ROTEX GS 28 Clamping Hub AL-H Design 2.5 Bore Ø 15 H7 Without Keyway - KTR 550287151550

KTR ✓ Original product Brand new Made in Germany

Clamping hub AL-H design 2.5 for the backlash-free ROTEX GS 28 servo coupling, bore Ø 15 H7, without keyway. On the Ø 15 mm shaft the hub is held by the clamping screw, frictionally and free of play. Combines with any size 28 GS spider.

Net
€82.20
excl. VAT
Item KTR-550287151550
Manufacturer no. 550287151550
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Clamping hub AL-H design 2.5 for the backlash-free ROTEX GS 28 servo coupling, bore Ø 15 H7, without keyway. On the Ø 15 mm shaft the hub is held by the clamping screw, frictionally and free of play.

Benefits

  • Bore Ø 15 mm to tolerance H7, ready to fit
  • No keyway, purely frictional connection
  • Backlash-free torque transmission together with the pre-tensioned size 28 GS spider
  • Compensates angular, radial and axial misalignment together with the spider

Applications

Shaft connection of servo motors, pumps and measuring shafts in servo hydraulics, test benches and automation. Together with a second hub and a size 28 spider, this clamping hub with Ø 15 mm bore makes a complete coupling.

Technical data

SeriesROTEX GS
Size28
ComponentClamping hub
Hub versionAL-H
Design2.5
BoreØ 15 mm
Bore toleranceH7
Keywaynone
Catalogue designationROTEX GS 28 AL-H clamp hub 2.5 Ø15H7 w/o key
KTR article no.550287151550
Customs tariff no.84839089
Weight0.31 kg
ManufacturerKTR
Hersteller-Nr550287151550
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungKlemmnabe
Bauform2.5
Bore (mm)15

Downloads

Datasheet

User Manual

Catalogue

Brochure

Accessories

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
