ROTEX GS 28 Spider 92 Sh-A-GS yellow for Backlash-Free Servo Coupling - KTR 550281000001

KTR ✓ Original product Brand new Made in Germany

The 92 Sh-A-GS spider is the flexible element of the ROTEX GS 28 and, at 92 Sh-A, sets how stiff and how well damped the drive runs. Its convex teeth sit under pre-tension in the jaws of the size 28 hubs and transmit torque without backlash.

Net
€10.36
excl. VAT
Item KTR-550281000001
Manufacturer no. 550281000001
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Replacement or alternative 92 Sh-A-GS spider for the ROTEX GS 28. The 92 Sh-A-GS spider is the flexible element of the ROTEX GS 28 and, at 92 Sh-A, sets how stiff and how well damped the drive runs.

Benefits

  • Backlash-free torque transmission through pre-tension in the size 28 jaw profile
  • 92 Sh-A hardness, softer than the Sh-D spiders of the GS range
  • Compensates angular, radial and axial shaft misalignment
  • Yellow colour coding makes the hardness easy to identify

Applications

Spider replacement on existing ROTEX GS 28 couplings, or matching the 92 Sh-A hardness to the control behaviour in servo hydraulics, test benches and automation.

Technical data

SeriesROTEX GS
Size28
ComponentSpider
Type92 Sh-A-GS
Shore hardness92 Sh-A
Colouryellow
Catalogue designationROTEX GS 28 spider 92 Sh-A-GS yellow
KTR article no.550281000001
Customs tariff no.84839089
Weight0.03 kg
ManufacturerKTR
Hersteller-Nr550281000001
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungZahnkranz

Downloads

Datasheet

User Manual

Catalogue

Brochure
