ROTEX GS 28 Spider 80 Sh-A-GS blue for Backlash-Free Servo Coupling - KTR 550281000003
At 80 Sh-A this ROTEX GS 28 spider determines how much torsional stiffness and damping the servo coupling provides. Its convex teeth sit under pre-tension in the jaws of the size 28 hubs and transmit torque without backlash. The blue colour identifies the hardness at a glance during assembly.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
80 Sh-A-GS spider for the ROTEX GS 28 servo coupling. At 80 Sh-A this ROTEX GS 28 spider determines how much torsional stiffness and damping the servo coupling provides.
Benefits
- Backlash-free torque transmission through pre-tension in the size 28 jaw profile
- 80 Sh-A hardness, softer than the Sh-D spiders of the GS range
- Compensates angular, radial and axial shaft misalignment
- Blue colour coding makes the hardness easy to identify
Applications
Spider replacement on existing ROTEX GS 28 couplings, or matching the 80 Sh-A hardness to the control behaviour in servo hydraulics, test benches and automation.
Technical data
| Series | ROTEX GS |
|---|---|
| Size | 28 |
| Component | Spider |
| Type | 80 Sh-A-GS |
| Shore hardness | 80 Sh-A |
| Colour | blue |
| Catalogue designation | ROTEX GS 28 spider 80 Sh-A-GS blue |
| KTR article no. | 550281000003 |
| Customs tariff no. | 84839089 |
| Weight | 0.03 kg |
| Manufacturer | KTR |
| Hersteller-Nr | 550281000003 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Ausführung | Zahnkranz |
