ROTEX GS 38 Intermediate Tube ZR3 LR 457 mm with 2 Bonded Hubs - KTR 550380940457

KTR ✓ Original product Brand new Made in Germany

Zero backlash over distance: ROTEX GS 38 intermediate tube ZR3 with a 457 mm tube length LR and two bonded hubs. The pre-tensioned spider transmits torque without play and compensates shaft misalignment.

Net
€452.32
excl. VAT
Item KTR-550380940457
Manufacturer no. 550380940457
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The ZR3 intermediate tube of the ROTEX GS 38 bridges the distance between driving and driven shaft with a tube length LR of 457 mm. A pre-tensioned spider with convex teeth sits in the concave jaws of the hubs and keeps the connection free of backlash.

Benefits

  • Tube length LR 457 mm as a fixed dimension for the shaft gap
  • Supplied with 2 bonded hubs as a ready-to-fit unit
  • No reversal backlash thanks to the pre-tensioned spider
  • Compensates angular, radial and axial shaft misalignment

Applications

The series is mainly chosen for servo hydraulics, test benches and automation technology, where positioning accuracy is decisive. Check dimensions and the combination with hubs and spider for size 38 against the KTR dimension sheet before ordering.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR457 mm
HS code84839089
KTR article no.550380940457
Weight0.71 kg
Hersteller-Nr550380940457
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure

Accessories
