ROTEX GS 38 Intermediate Tube ZR3 LR 381 mm with 2 Bonded Hubs - KTR 550380940381

KTR ✓ Original product Brand new Made in Germany

Backlash-free connection across a shaft gap: ROTEX GS 38 intermediate tube ZR3 with a 381 mm tube length LR and two bonded hubs. The pre-tensioned spider transmits torque without play and compensates shaft misalignment.

Net
€452.32
excl. VAT
Item KTR-550380940381
Manufacturer no. 550380940381
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The ROTEX GS 38 intermediate tube ZR3 comes with a tube length LR of 381 mm and two hubs already bonded in place. Within the coupling, the spider with convex teeth, fitted under pre-tension, ensures backlash-free running.

Benefits

  • Bridges the gap between the shaft ends with LR 381 mm
  • Two hubs already bonded to the tube, which saves assembly steps
  • No reversal backlash thanks to the pre-tensioned spider
  • Axial, radial and angular misalignment compensation

Applications

Fields of use: servo hydraulics, test bench technology and automation that need backlash-free, accurately positioning power transmission. Matching hubs and spiders of the same size 38 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size38
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR381 mm
HS code84839089
KTR article no.550380940381
Weight0.71 kg
Hersteller-Nr550380940381
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure
