ROTEX GS 19 Clamping Hub AL-H 2.1 Bore Ø 24 mm H7 with keyway, 2 clamping screws M4 - KTR 550197152449

KTR ✓ Original product Brand new Made in Germany

ROTEX GS 19 clamping hub with bore Ø 24 mm H7, with keyway for backlash-free servo drives. On the Ø 24 mm shaft the keyway adds security to the clamp.

Net
€56.76
excl. VAT
Item KTR-550197152449
Manufacturer no. 550197152449
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

As the drive or driven side of the ROTEX GS 19, this clamping hub takes up the shaft. On the Ø 24 mm shaft the keyway adds security to the clamp. Because the ROTEX GS spider is fitted under pre-tension, its convex teeth engage the concave hub jaws without play.

Benefits

  • Bore Ø 24 mm H7 for an accurate shaft fit
  • With keyway for positive drive
  • 2 clamping screws M4
  • Backlash-free together with the ROTEX GS spider
  • Combines with GS 19 spiders in 80 Sh-A, 92 Sh-A, 98 Sh-A, 57 Sh-D and 64 Sh-D-H

Applications

It is specified in automation, on test benches and in servo hydraulics when readings and positions must be free of reversal backlash.

Technical data

ManufacturerKTR
Article number550197152449
SeriesROTEX GS
SizeGS 19
ComponentClamping Hub
Hub designAL-H 2.1
BoreØ 24 mm H7
Keywayyes
Clamping screws2 x M4
Weight0.06 kg
Customs tariff number84839089
Hersteller-Nr550197152449
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungKlemmnabe AL-H 2.1, Bohrung Ø 24 mm H7, mit Passfedernut
Bore (mm)24

Downloads

Datasheet

User Manual

Catalogue

Brochure
