ROTEX GS 19 Spider 57 Sh-D light blue for Backlash-Free Servo Coupling - KTR 550191000014

KTR ✓ Original product Brand new Made in Germany

Spider 57 Sh-D in light blue for the ROTEX GS 19: its convex teeth sit under pre-tension between the hubs and transmit torque without backlash. The Shore hardness 57 Sh-D sets the torsional stiffness and damping of the coupling.

Net
€9.48
excl. VAT
Item KTR-550191000014
Manufacturer no. 550191000014
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The 57 Sh-D spider is the flexible core of the ROTEX GS 19. It is fitted with pre-tension between the concave jaws of the two hubs. In the ROTEX GS the spider with convex teeth sits under pre-tension in the concave jaws of the hubs, so torque is transmitted without backlash.

Benefits

  • Hardness 57 Sh-D sets the torsional stiffness and damping of the coupling
  • Colour light blue identifies hardness 57 Sh-D during installation and maintenance
  • Backlash-free torque transmission through pre-tensioned convex teeth
  • Compensates angular, radial and axial misalignment flexibly
  • Further GS 19 hardnesses in the range: 80 Sh-A, 92 Sh-A, 98 Sh-A and 64 Sh-D-H

Applications

Typical applications are servo drives in automation, test benches and servo-hydraulic axes, where backlash-free positioning matters.

Technical data

ManufacturerKTR
Article number550191000014
SeriesROTEX GS
SizeGS 19
ComponentSpider
Shore hardness57 Sh-D
Colourlight blue
Customs tariff number84839089
Weight0.71 kg
Hersteller-Nr550191000014
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure

Accessories

Alternatives

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
