ROTEX GS 19 Clamping Ring Hub AL-H light 6.0 Bore Ø 12 mm H7 - KTR 550197151290

KTR ✓ Original product Brand new Made in Germany

ROTEX GS 19 clamping ring hub with bore Ø 12 mm H7 for backlash-free servo drives. The Ø 12 mm shaft is gripped by the clamping ring by friction.

Net
€79.77
excl. VAT
Item KTR-550197151290
Manufacturer no. 550197151290
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The size GS 19 clamping ring hub is the link between shaft and spider. The Ø 12 mm shaft is gripped by the clamping ring by friction. Because the ROTEX GS spider is fitted under pre-tension, its convex teeth engage the concave hub jaws without play.

Benefits

  • Bore Ø 12 mm H7 for an accurate shaft fit
  • Backlash-free together with the ROTEX GS spider
  • Combines with GS 19 spiders in 80 Sh-A, 92 Sh-A, 98 Sh-A, 57 Sh-D and 64 Sh-D-H

Applications

It is specified in automation, on test benches and in servo hydraulics when readings and positions must be free of reversal backlash.

Technical data

ManufacturerKTR
Article number550197151290
SeriesROTEX GS
SizeGS 19
ComponentClamping Ring Hub light
Hub designAL-H light 6.0
BoreØ 12 mm H7
Weight0.09 kg
Customs tariff number84839089
Hersteller-Nr550197151290
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungSpannringnabe AL-H light 6.0, Bohrung Ø 12 mm H7
Bore (mm)12

Downloads

Datasheet

User Manual

Catalogue

Brochure
