ROTEX GS 19 Hub AL-H 1.0 Bore Ø 22 mm H7 Keyway DIN 6885-1 JS9 - KTR 550197102200

KTR ✓ Original product Brand new Made in Germany

The ROTEX GS 19 hub connects the shaft to the pre-tensioned spider, bore Ø 22 mm H7, keyway DIN 6885-1 JS9. The Ø 22 mm H7 bore with keyway to DIN 6885-1 (tolerance JS9) transmits torque by positive locking.

Net
€31.60
excl. VAT
Item KTR-550197102200
Manufacturer no. 550197102200
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

This hub forms one half of the ROTEX GS 19. The Ø 22 mm H7 bore with keyway to DIN 6885-1 (tolerance JS9) transmits torque by positive locking. Convex spider teeth, concave hub jaws and a defined pre-tension make the ROTEX GS a backlash-free servo coupling.

Benefits

  • Bore Ø 22 mm H7 for an accurate shaft fit
  • Keyway to DIN 6885-1, tolerance JS9
  • No reversal backlash thanks to the pre-tensioned spider
  • Combines with GS 19 spiders in 80 Sh-A, 92 Sh-A, 98 Sh-A, 57 Sh-D and 64 Sh-D-H

Applications

Applications include servo hydraulics, test bench construction and linear or rotary axes that call for precise positioning.

Technical data

ManufacturerKTR
Article number550197102200
SeriesROTEX GS
SizeGS 19
ComponentHub
Hub designAL-H 1.0
BoreØ 22 mm H7
KeywayDIN 6885-1, JS9
Weight0.07 kg
Customs tariff number84839089
Hersteller-Nr550197102200
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungNabe AL-H 1.0, Bohrung Ø 22 mm H7, Nut DIN 6885-1 JS9
NormDIN 6885-1
Bore (mm)22
