ROTEX 90 Hub steel, unbored - KTR 020905000040
Coupling hub for the ROTEX 90 jaw coupling in steel, unbored. Mounts on the shaft and transmits torque through the spider.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
ROTEX is a torsionally flexible jaw coupling from KTR. It transmits torque positively through an elastomer spider between two jaw hubs and compensates angular, radial and axial shaft misalignment. If the spider wears, the jaws engage with each other so the coupling stays fail-safe.
Benefits
- Sturdy hub for durable torque transmission
- Supplied unbored for machining to shaft size
- Combines with any ROTEX 90 spider
Applications
A complete coupling needs two hubs and one spider of size 90.
Technical data
| Size | ROTEX 90 |
|---|---|
| Material | steel |
| Bore | unbored |
| Weight | 20.45 kg |
| Manufacturer | KTR |
| Hersteller-Nr | 020905000040 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Series | ROTEX |
