ROTEX GS 9 clamping hub AL-H 2.0 bore Ø 12 mm F7 without keyway DH22 - KTR 550097151251

KTR ✓ Original product Brand new Made in Germany

This clamping hub 2.0 takes a Ø 12 mm shaft and integrates it into the backlash-free ROTEX GS 9 servo coupling. No keyway is needed on the Ø 12 mm shaft of the ROTEX GS 9 clamping hub 2.0.

Net
€20.17
excl. VAT
Item KTR-550097151251
Manufacturer no. 550097151251
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

This clamping hub 2.0 takes a Ø 12 mm shaft and integrates it into the backlash-free ROTEX GS 9 servo coupling. Backlash-free and flexible: the ROTEX GS principle.

Benefits

  • Backlash-free in the ROTEX GS 9 thanks to the pre-tensioned spider
  • Bore Ø 12 mm F7 for the matching drive or driven shaft
  • Clamping hub design 2.0 for mounting on the shaft
  • Compensates angular, radial and axial misalignment between the shafts

Applications

Servo motor drives in test bench technology and automation that need a ROTEX GS 9 with this clamping hub.

Technical data

ManufacturerKTR
KTR part number550097151251
SeriesROTEX GS
Size9
ComponentClamping hub
Design2.0
Hub codeAL-H
BoreØ 12 mm
Bore toleranceF7
Keywaynone
DH codeDH22
Weight0.01 kg
Customs tariff number84839089
Manufacturer designationRotex GS 9 AL-H Klemmnabe 2.0 D.12F7 ohne Nut DH22
Hersteller-Nr550097151251
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungKlemmnabe 2.0
Bore (mm)12
