ROTEX GS 55 Spider 57 Sh-D-GS light blue, inner Ø 22.5 mm - KTR 550551000014

KTR ✓ Original product Brand new Made in Germany

57 Sh-D-GS spider in light blue for the backlash-free ROTEX GS 55 servo coupling. Its Shore hardness sets stiffness and damping, and the convex teeth sit under pre-tension in the hubs to keep the drive free of backlash.

Net
€47.99
excl. VAT
Item KTR-550551000014
Manufacturer no. 550551000014
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The 57 Sh-D-GS spider is the flexible transmission element of the ROTEX GS 55, and its hardness sets the stiffness and damping of the coupling. Zero backlash comes from the pre-tensioned spider, whose convex teeth engage the concave jaws of the hubs.

Benefits

  • Shore hardness 57 Sh-D as the key value for stiffness and damping
  • Inner Ø 22.5 mm for size 55
  • Convex teeth fitted under pre-tension for backlash-free running
  • Stiffness and damping matched through different spider hardnesses
  • Absorbs radial, axial and angular offset between the shafts

Applications

The series is mainly chosen for servo hydraulics, test benches and automation technology, where positioning accuracy is decisive. Matching hubs and spiders of the same size 55 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size55
ComponentSpider
Hardness57 Sh-D-GS
Colourlight blue
Inner diameterØ 22.5 mm
HS code84839089
KTR article no.550551000014
Weight0.71 kg
Hersteller-Nr550551000014
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Shore hardness57 Sh-D
Bore (mm)22.5
