ROTEX GS 48 ST-H Driving Flange for RUFLEX 3 and SYNTEX 50 - KTR 550485850023
Links the servo coupling to the torque limiter: ROTEX GS 48 ST-H driving flange for RUFLEX 3 and SYNTEX 50. For servo hydraulics, test benches and automation, where zero backlash and positioning accuracy count.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The driving flange ST-H connects the ROTEX GS 48 to the KTR RUFLEX 3 torque limiter and to SYNTEX 50. The coupling works torsionally flexible and backlash-free because the spider is held with pre-tension between the hub jaws.
Benefits
- Fits RUFLEX 3 and SYNTEX 50
- Material steel (ST-H)
- No reversal backlash thanks to the pre-tensioned spider
- Component weight 2.21 kg
Applications
Users fit the coupling in servo hydraulics, test bench technology and automation, where reversal backlash would cost accuracy. Matching hubs and spiders of the same size 48 are available separately.
Technical data
| Manufacturer | KTR |
|---|---|
| Series | ROTEX GS |
| Size | 48 |
| Component | Driving flange |
| Code | ST-H (steel) |
| Suitable for | RUFLEX 3, SYNTEX 50 |
| Weight | 2.21 kg |
| HS code | 84839089 |
| KTR article no. | 550485850023 |
| Hersteller-Nr | 550485850023 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Material | Steel |
