ROTEX GS 48 ST-H Hub 1.0, Bore Ø 38 mm H7, Keyway DIN 6885/1-JS9 - KTR 550485003800

KTR ✓ Original product Brand new Made in Germany

Hub for the backlash-free servo coupling: ROTEX GS 48 ST-H hub 1.0, bore Ø 38 mm H7. The pre-tensioned ROTEX GS spider transmits torque without backlash and compensates shaft misalignment.

Net
€198.43
excl. VAT
Item KTR-550485003800
Manufacturer no. 550485003800
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For Ø 38 mm H7 shafts, KTR supplies the ROTEX GS 48 hub 1.0 ST-H, which transmits torque through the key. KTR designs the ROTEX GS as a backlash-free, torsionally flexible servo coupling whose spider is fitted under pre-tension.

Benefits

  • Bore Ø 38 mm H7 fully machined
  • Keyway to DIN 6885/1, tolerance JS9
  • Hub material steel (ST-H)
  • Backlash-free torque transmission through the pre-tensioned spider
  • Takes up angular, radial and axial misalignment in the drive train
  • Component weight 3.12 kg

Applications

The ROTEX GS is used in servo hydraulics, test bench construction and automation wherever precise positioning is required. Before installation, check that the other coupling parts are size 48.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size48
ComponentHub
CodeST-H (steel)
Version1.0
BoreØ 38 mm
Bore toleranceH7
KeywayDIN 6885/1, JS9
Weight3.12 kg
HS code84839089
KTR article no.550485003800
Hersteller-Nr550485003800
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
MaterialSteel
NormDIN 6885-1
Bore (mm)38
